2006 KIT
PARTS NUMBER	DESCRIPTION	REMARK
06110-NL9-C00	ENGINE POWER UP KIT V,SBK	S
06110-NL9-C30	ENGINE POWER UP KIT V,JSB	J
06120-NL9-C00	ENGINE POWER UP KIT IV,SBK	S
06180-NL9-710	CAM SPROCKET SET,JSB	J
06160-NL9-710	AIR FUNNEL SET	S,J
06160-NL9-C30	AIR FUNNEL SET (OPTION)	S,J
06230-NL9-C00	BTL CLUTCH SET,SBK	S
06240-NL9-C00	CRANKCASE SET, SBK	S
06250-NL9-C00	WASHER,CRANK SHAFT SET,SBK	S
06260-NL9-C00	OIL PAN SET, SBK	S
06270-NL9-C00	R COVER SET, SBK,JSB	S
06130-NL9-C00	ACG SET, SBK,JSB	J
06183-NL9-C00	EXHAUST SET, Ti (SBK)	S
06183-NL9-C30	EXHAUST SET, Ti (JSB)	J
52460-MEL-R10	ARM ASSY, CUSHION	*
52460-NL9-C00	ARM ASSY, CUSHION (P2)	S,J
52460-NL9-C10	ARM ASSY, CUSHION (P4)	S,J
52470-MEL-R10	CONN ROD ASSY, CUSHION	*
52470-NL9-C00	CONN ROD ASSY, CUSHION (P2)	S,J
52470-NL9-C10	CONN ROD ASSY, CUSHION (P4)	S,J
19100-MEL-R31	RADIATOR COMP '06R/B STD	*
06321-NL9-C00	HARNESS SET	S,J
38771-NL9-C00	CD-ROM, PGM-FI/IGN	S,J
06324-NL9-C00	BATTERY & CABLE SET	S,J
38880-NL9-C00	UNIT ASSY, SERIAL I/F (USB TYPE)	S,J
38880-NL3-750	UNIT ASSY, SERIAL I/F (RS232C TYPE)	S,J
38772-NL9-C00	COUPLER ASSY, MODE (WET)	S,J
38773-NL9-C00	COUPLER ASSY, MODE (STD)	S,J

*: assembled in '06 race base bikes
S: for FIM Superbike race
J: for MFJ Superbike race

2006 JSB ENDURANCE PARTS LINE-UP
PARTS NUMBER	DESCRIPTION	QTY
06110-NL9-C40	ENGINE POWER UP KIT V,(JSB-E)	-

14110-MEL-R10	CAM SHAFT COMP,IN	1
14210-NL9-C40	CAM SHAFT COMP,EXH(JSB-E)	1
14321-NL9-C40	SPROCKET,CAM(JSB-E)	2
14751-NL9-C40	SPG,IN VALVE OUTER(JSB-E)	8
14752-MEL-D20	SPG,IN VALVE INNER	8
14761-NL9-C40	SPG,EX VALVE(JSB-E)	8
90082-NL9 -710	BOLT,FLANGE KNOCK,7X10.5	4
90488-425 -000	WAHSER,SEALING 6MM	2

38770-NL9-C40

UNIT ASSY PGM-FI/IGN(JSB-E)

1

All contents and specifications are subject to change without notice, to improve the motorcycles.
