| 2005 KIT |
| PARTS NUMBER |
DESCRIPTION |
| 06180-NL3-900 |
EXHAUST SET(SS) |
| 06190-NL3-900 |
SUB RADIATOR SET |
| 06537-NL3-900 |
DAMPER SET, STRG. |
| 06304-NL3-900 |
ELECTRIC SET(SS) |
| 38771-NL3-900 |
CD-ROM, PGM-FI/IGN SS |
| 45105-NL9-801 |
PAD COMP, FR(N614) |
| 45105-NL3-921 |
PAD COMP, FR(H21A) |
| 45106-NL3-921 |
PAD COMP, FR(N608) |
| 45125-NL3-901 |
HOSE COMP, FR BREAK |
| 45120-NL3-900 |
DISC COMP, R FR
BRK(5mm) |
| 45220-NL3-900 |
DISC COMP, L FR
BRK(5mm) |
| 51404-NL3-921*1 |
COLLAR B, SPRING |
| 51406-NL3-921*2 |
STOPPER, SPRINGSHEET |
| 51401-NL3-921 |
SPRING, FR
CUSHION(0.90) |
| 51401-MEE-R21 |
SPRING, FR
CUSHION(0.95) |
| 51402-NL3-921 |
SPRING, FR
CUSHION(1.00) |
| 51403-NL3-921 |
SPRING, FR
CUSHION(1.05) |
| 52401-NL3-921 |
SPRING, RR
CUSHION(10.5) |
| 52401-MEE-D01 |
SPRING, RR
CUSHION(11.0) |
| 52402-NL3-921 |
SPRING, RR
CUSHION(11.5) |
| 52403-NL3-921 |
SPRING, RR
CUSHION(12.0) |
- When you change a front spring, please exchange *2 and *3 together as a
set.
- Except brake disc, all parts are exclusive for 05 year model CBR600RR.
| 2004 KIT |
| PARTS NUMBER |
DESCRIPTION |
| 06130-NL3-751 |
ENGINE POWER-UP KIT(SS) |
| 06230-NL3-750 |
TRANSMISSION SET(SS) |
| 31100-NL3-750 |
ACG ASSY. |
| 06170-NL3-750 |
AIR FUNNEL SET |
| 06180-NL3-750 |
EXHAUST SET(SS) |
| 06190-NL3-850 |
SUB RADIATOR SET |
| 06304-NL3-752 |
ELECTRIC SET(SS) |
| 06531-NL3-750 |
HOUSING SET, THROTTLE |
| 06537-NL3-750 |
DAMPER SET, STRG |
| 06552-NL3-750 |
BREATHER CASE SET |
| 17910-NL3-750 |
CABLE COMP. A, THROT |
| 17920-NL3-750 |
CABLE COMP. B, THROT |
| 37100-NL3-751 |
METER ASSY. COMB (FIM) |
| 37100-NL3-761 |
METER ASSY, COMB(AMA) |
| 38771-NL3-750 |
CD-ROM, PGM-FI/IGN |
| 38880-NL3-750 |
UNIT ASSY, SERIAL |
| 43105-NL3-750 |
PAD COMP, A RR(MNX9) |
| 43106-NL3-750 |
PAD COMP, B RR(MNX9) |
| 43105-NL3-760 |
PAD COMP, A RR(NKX16) |
| 43106-NL3-760 |
PAD COMP, B RR(NKX16) |
| 45105-NL3-750 |
PAD COMP, FR(S20A) |
| 45105-NL3-760 |
PAD COMP, FR(N614) |
| 45105-NL3-850 |
PAD COMP, FR(S20A,
LT5) |
| 45105-NL3-860 |
PAD COMP, FR(S20A,
PT5) |
| 45120-NL3-750 |
DISC COMP, R FR BREAK |
| 45125-NL3-850 |
HOSE COMP, FR BREAK |
| 45220-NL3-750 |
DISC COMP, L FR BREAK |
| 51407-NL3-750 |
SPRING, FR CUSHION
0.85 |
| 51408-NL3-750 |
SPRING, FR CUSHION
0.90 |
| 51409-NL3-750 |
SPRING, FR CUSHION
0.95 |
| 51410-NL3-750 |
SPRING, FR CUSHION
1.00 |
| 52403-NL3-750 |
SPRING, RR CUSHION
10.0 |
| 52404-NL3-750 |
SPRING, RR CUSHION
12.0 |
| 52401-NL3-750 |
SPRING, RR CUSHION
10.5 |
| 52402-NL3-750 |
SPRING, RR CUSHION
11.5 |
| 17220-NL3-760 |
ELEMENT, AIR CLEANER |
| 31910-NL3-870 |
PLUG, SPARK R0409B-10 |
| 31910-NL3-651 |
PLUG, SPARK R0379B-10 |
| 00X32-NL3-850 |
SET UP MANUAL/PARTS
LIST |
|
