I-VAC Major Ratings

Major Ratings specifications and Characteristics of "I-VAC"

Characteristics		Values	Units
IF	forward (max)	40	A
VF	forward (max)	60	V
TU	range	- 55 to 140	°C

Stability 0.1 Percent
Correction accuracy 0.1 Percent
Voltage adjustment every 0.01Voltage
Maximum operating unit temperature 140°C
Max Watt age 600W
Very small conduction losses
Efficiency 95 Percent
Heavy-duty High temp Fuse Box

Ultra Extremely fast voltage amp feedback and control system

S&R Engineering has developed ultra extremely fast voltage and amp feedback control system.

This S&R Engineering "Nano Feedback Control System" are achievement to controlled speed by nano second.

Extremely fast high power forward transfer admittance.

I-VAC has been optimized for very low forward voltage drop, with moderate leakage.

The S&R Engineering technology allows for reliable operation from -55°C to up to 140°C unit temperature.

possible to set Voltage every 0.01voltage , from 12.5v to 60v

Spec of Automotive Wire Harness (AWG12)

Size AWG	Copper Stranding	Conductor OD Inches	Insulation Thickness	Finished OD Inches	Finished Weight lbs/Mft	OHMS Resistance/ Mft	Ampacity 30°C (86°F) Ambient	Ampacity 40°C (104°F) Ambient
12 AWG	(65/30) tinned	0.089	0.030	0.149	31	1.680	44	41

Note: Ampacities based on single conductor in free air, 30°C (86°F) or 40°C (104°F)

ambient temperature as specified, 105°C (221°F) conductor temperature, per table

310-17 of the NEC (adjusted for 105°C). Free air ratings assume a one cable diameter

spacing between adjacent conductors.

Insulation Properties

Properties	Results	Test methods
Specific Gravity (±.02)	1.30	ASTM D-792
Durometer Shore "A"	77/65	ASTM D-2240
(±.02) INST./15 seconds
Tensile Strength (60 mil)	2000	ASTM D-412
Elongation (%)	300	ASTM D-412
Brittle Point (C)	-55	ASTM D-746
Oxygen Index %	25.0	ASTM D-2863
Oil Aged 18 Hours @ 121°C
% Retention of Tensiles	129	UL Standard
% Retention of Elongation	72	UL Standard
Air Aged 7 Days @ 136°C
% Retention of Tensiles	109	ASTM D412-80
% Retention of Elongation	100	ASTM D412-80
Oil Aged 7 Days @ 60°C
% Retention of Tensiles	124	ASTM D412-80
% Retention of Elongation	89	ASTM D412-80
VW-1 Flame Test	Pass	UL Standard
Product Cold Bend Test	Pass	UL Standard
Voltage Rating600	UL Standard
